What is Plastic Injection Molding
Plastic injection molding is a manufacturing process that involves the production of plastic parts by injecting molten plastic material into a mold or tool. The process begins with the design of the mold, which is usually made from steel or aluminum, and shaped according to the final product specifications. Once the mold is designed, the plastic injection molding process involves the melting of plastic material pellets or resin in a heated barrel, where it is extruded through a nozzle and injected into the mold cavity. The plastic material is then allowed to cool and solidify to the shape of the mold. After the plastic has cooled and solidified, the mold is opened and the finished product is ejected from the mold cavity. The process is highly efficient and produces high-quality and consistent parts at a relatively low cost. The plastic injection molding process can be used to produce a wide range of products, from small precision parts to large, complex assemblies.
Benefits of Electric Plastic Mold
High efficiency
Plastic injection molding process hardly takes times and this allows more parts to be manufactured from a single mold. The high production output rate makes plastic injection molding more cost effective and efficient. Typically, hot-runner ejection mold systems produce parts with more consistent quality and do so with faster cycle times, but it's not as easy to change colors nor can hot runners accommodate some heat-sensitive polymers.
Save manufacturing costs
Plastic injection molding is an automated process. A majority of the injection molding process is performed by machines and robotics which a sole operator can control and manage. Automation helps to reduce manufacturing costs, as the overheads are significantly reduced. Furthermore, with reduced labor force the overall cost of manufacturing the parts is reduced and this cost saving can easily be passed on to the customer.
Versatility
One of the major advantages of using plastic injection molding for manufacturing parts is the ability to use different types of plastic simultaneously. This can be done with the help of co-injection molding, which takes away the worry about using a specific type of plastic.
Enhanced strength
In plastic injection molding, it is possible to use fillers in the injection molds. These filler reduce the density of the plastic while it being molded and also help in adding greater strength to the part after it has been molded. In fields where parts need to be strong and durable, plastic injection has an option that other molding processes do not offer.
Plastic injection molding for your production runs
Are you about to start high-volume production? Do you have a hard time polishing manufacturing cycles so that they don’t cost you a fortune? Let Deep Mould, an established plastic injection molding company, help your team from a concept to a real complete part directly sale to the final market.
With the immense expertise behind, we specialize in simplifying once complex production processes for our customers. Our molding services can be perfectly tailored to your conception, part design, prototype make with 3D printing or CNC machining, then confirm the part design, start to make the mold tooling, also the plastic injection of parts, color printing, laser machining, part assembling and package design. No matter the number of parts that you’re going to make, we’re in a position to expedite turnaround times and take the hassle out of the process.
What’s more, our injection plastic molding services will help:
- Enhance the functionality of your items
- Cut down your manufacturing expenses
- Launch several production runs at the same time
- Ensure identical features in your parts
- Save time and money on finishing
- One-stop service for the plastic part assembling and package service
ISO-certified services for plastic injection molding in China
Deep Mould utilizes industry-leading single- and multi-chamber machinery to produce plastic parts. We also use a variety of thermoplastic elastomers and high-performance polymers, including PPSU, PEI, etc. Our dedication to quality has allowed us to receive international certification as a plastic injection molding manufacturer. Through the range of control procedures, our team monitors every manufacturing step to ensure compliance with global standards.
It goes to show that Deep Mould can take the project of any complexity to the next level. We cover many industries and can produce everything from wheelchair wheels and fans to LED light protection units and automotive parts.
Injection plastic molding coupled with professional DFM analysis This analysis is pivotal to any production project. It is carried out to make sure that the design features of your parts fit the molding process before we start it. If there’s room for some tweaks, we’ll help you determine them.
We perform the plastic part design service and a systematic DFM analysis in a bid to:
- Perfect the design of your custom parts
- Free cost for moldflow analysis of the plastic part filling
- Eliminate the risk of assembly issues
- Maintain the outstanding quality of the items being made
- Maximize your savings down the road
To request a part design or a plastic mold DFM analysis, get a quote, or send us your production drawings, please contact us. Deep Mould is a trusted plastic injection mould manufacturer that will meet all your project goals!
Why Choose US
Innovation
We are dedicated to improving our systems continually, ensuring that the technology we offer is always cutting edge.
One stop solution
We can offer a range of services, from consultation and advice to product design and delivery. It is a convenience for the customers, as they can get all the help they need in one place.
24h online service
We try and respond to all concerns within 24 hours and our teams are always at your disposal in case of any emergencies.
Professional team
Our professional team collaborate and communicate effectively with one another, and are committed to delivering high-quality results. They are capable of handling complex challenges and projects that require their specialized expertise and experience.
Types of Plastic Injection Molding
Thermoplastic injection molding
This is the most common type of plastic injection molding, where thermoplastic materials like ABS, PE, PP, and PVC are used to produce a wide range of products.
Thermoset injection molding
This type of molding involves the use of thermosetting plastics like epoxy, melamine, and phenolic resins. These materials are heated until they cure or harden, and they cannot be melted again once they have solidified.
Micro injection molding
This type of molding is used to produce very small and intricate parts with tight tolerances. Micro molding is commonly used in the production of medical devices, microfluidic devices, and electronics components.
Multi-component injection molding
This process involves the use of different materials, colors, and textures to produce a single plastic part. Multi-component molding is commonly used in the production of consumer goods, automotive components, and medical devices.
Plastic injection molded components
- Hopper: The opening where plastic granules are fed into the machine.
- Housings: The outer housing of the injection molding machine, which contains the reciprocating screw and the plastic granules. The barrel is wrapped in several heater bands and is tipped with a heated nozzle.
- Reciprocating screw: The corkscrew component that conveys and pressurizes the plastic material as it melts through the barrel.
- Heaters: Also known as heating bands, these components provide thermal energy to the plastic granules, turning them from a solid form to a liquid. form.
- Movable platen: The moving component connected to the mold core that applies pressure to keep both mold halves airtight and also releases the mold core when revealing the finished part.
- Nozzle: The heated component that provides a standard outlet for molten plastic into the mold cavity, keeping both temperature and pressure as stable as possible.
- Mold: The component or components that contain the mold cavity and additional supporting features like ejector pins, runner channels, cooling channels, vents, etc. At a minimum, molds are separated into two halves: the stationary side (closer to the barrel) and the mold core (on the moving platen).
- Mold cavity: The negative space that, when filled with molten plastic, will shape it into the desired final part plus supports, gates, runners, sprues, etc.
Once the plastic has filled the mold including its sprues, runners, gates, etc., the mold is kept at a set temperature to allow uniform solidification of the material into the part shape. A holding pressure is maintained while cooling to both stop backflow into the barrel and reduce shrinking effects. At this point, more plastic granules are added to the hopper in expectation of the next cycle (or shot). When cooled, the platen opens and allows the finished part to be ejected, and the screw is drawn back once more, allowing material to enter the barrel and start the process over again.The injection molding cycle works by this continuous process—closing the mold, feeding/heating the plastic granules, pressurizing them into the mold, cooling them into a solid part, ejecting the part, and closing the mold again. This system allows for the rapid production of plastic parts, and upwards of 10,000 plastic parts can be made in a workday depending upon the design, size, and material.
How to Use Plastic Injection Molding
Designing the part
The first step in the process is designing the part that needs to be produced. This can be done using computer-aided design (CAD) software.
Creating the mold
The next step is creating the mold that will be used to shape the plastic. The mold is typically made from steel or aluminum and is designed to be able to withstand the high pressures and temperatures involved in the injection molding process.
Preparing the plastic
Plastic pellets are fed into a hopper, where they are melted and mixed. The melted plastic is then injected into the mold cavity.
Injection
The plastic is injected into the mold at high pressure, where it fills the entire cavity and takes on the shape of the mold.
Cooling
Once the plastic has been injected into the mold, it needs to be cooled in order to solidify. The mold is typically cooled using water or air.
Ejection
Once the plastic has cooled and solidified, the mold is opened and the part is ejected.
Finishing
The final step in the process is finishing the part, which may involve trimming any excess plastic and adding any necessary features or surface finishes.
Application Areas of Plastic Injection Molding
Automotive
Plastic injection molding is frequently used to produce a wide array of automotive parts, such as interior and exterior trim, electronic housings, and engine components. The high precision and consistency of injection molding make it ideal for producing complex parts that must meet strict performance and safety standards.
Medical devices
Injection molding is an important manufacturing method for creating medical devices and equipment. This includes everything from surgical instruments to implantable devices like pacemakers. Injection molding allows manufacturers to produce high-quality, precise parts that are durable and safe for use in healthcare settings.
Consumer products
Plastic injection molding is used to produce all kinds of consumer products, from toys and games to household appliances and electronics. Injection molding is an efficient and cost-effective way to produce high volumes of identical parts quickly and easily.
Packaging
Injection molding is a popular method for producing plastic packaging, including food containers, bottles, caps, and lids. The ability to produce high-quality, consistent parts in large volumes makes injection molding an ideal choice for companies that need to produce large quantities of packaging quickly and efficiently.
Aerospace
Injection molding is used in the aerospace industry to produce lightweight, durable components that are essential for aircraft and spacecraft. Injection molding allows manufacturers to produce highly precise parts that meet rigorous safety and performance standards.
Construction and building materials
Injection molding is used to produce a variety of building materials, including PVC pipes, window frames, and insulation. The versatility of injection molding allows manufacturers to produce parts with a wide range of shapes, sizes, and material properties.
Materials Used in Plastic Injection Molding
Composite materials
Composite materials are made up of two or more materials combined to create a new material with improved properties. Examples of composite materials used in plastic injection molding include glass fiber-reinforced plastics, carbon fiber-reinforced plastics, and wood-plastic composites.
Thermoplastics
These are the most commonly used materials in plastic injection molding. They are plastics that can be melted and re-melted easily. Some of the most common types of thermoplastics include polyethylene, polypropylene, polystyrene, and PVC.
Rubber
Rubber is an elastic material that is commonly used in plastic injection molding to produce flexible parts. Synthetic rubber materials, such as silicone and neoprene, are commonly used in this process.
Thermoset plastics
These are plastics that are cured or set through a chemical reaction. Once set, they cannot be re-melted. Examples of thermoset plastics include epoxy, melamine, and phenolic resins.
Metal
Metal injection molding is often used to produce complex metal parts that cannot be created through traditional methods. Metals such as stainless steel, aluminum, and zinc are commonly used in this process.
How to Reduce the Cost of Using Plastic Injection Molding
Another way to lower the cost of plastic injection molding is to select the right material for your product. There are many different types of plastics available, and some of them are more expensive than others. Choosing a less expensive material that still meets your product's performance requirements can save you money.
Optimize the design
One of the most effective ways to reduce the cost of using plastic injection molding is to optimize the design of your product. By reducing the complexity of the design and using simpler shapes, you can decrease the amount of material used and reduce the manufacturing time. This will lower the overall cost of production.
Optimize the mold
The mold used in plastic injection molding is a major expense. Optimizing the design of the mold can help reduce manufacturing costs. For example, using a hot runner mold can reduce cycle time and waste material, resulting in lower costs.
Increase production volume
Increasing the production volume can help to reduce the cost per unit. Plastic injection molding is a highly automated process, and the cost of the equipment and molds can be spread over a larger number of units, resulting in lower costs per unit.
Maintenance of Plastic Injection Molding
Regular cleaning
Regular cleaning of the molding machine is a fundamental maintenance step that ensures the longevity and proper functioning of the equipment. The buildup of dirt, debris, or resin on the injection molding machine may cause wear and tear, creating an environment for potential equipment damage or even production failure. Cleaning the machine regularly ensures that the machine stays in excellent condition and can produce consistent and reliable parts.
Lubricating
Lubrication of the equipment is also crucial for proper maintenance of plastic injection molding equipment. Molding machines contain multiple moving parts that require periodic lubrication to keep them functioning efficiently and smoothly. Using the appropriate lubricants in the right quantities at the right time is critical to the consistency and quality of the injection molding process.
Repair worn parts
Thorough inspection of the mold, molding machine, and other peripheral equipment is another essential aspect of maintenance. Any wear and damage can quickly be identified through inspection, allowing for prompt repairs before they become significant issues. Regular inspection also allows operators to identify any parts that require replacement due to wear or fatigue, thereby reducing the risk of equipment failure or downtime.
Maintenance of the temperature control systems is another critical aspect of plastic injection molding. Temperature control systems ensure that the plastic is heated to the appropriate temperature for molding. Any deviation from the ideal molding temperature can impact the quality of the finished parts. Therefore, regular maintenance and calibration of the temperature control system is essential to maintain the consistency, quality, and reliability of the injection molding process.
Things to Note When Using Plastic Injection Molding
Plastic injection molding is a manufacturing process that is used to produce a wide range of plastic products using molds. It is a highly effective method that is used to create complex shapes and designs, making it a popular option for producing products for a variety of industries such as automotive, medical, household appliances, and electronics, among others.
Material selection
The type of plastic material you choose will affect the quality of the final product. It is essential to select the right material for the required function and the desired properties, such as strength, flexibility, or temperature resistance.
Mold design
The mold design is critical to producing high-quality products with minimal defects. It is important to work with an experienced mold designer who understands the requirements of your project and can create a mold that will deliver the desired results.
Injection molding machine
The selection of the machine is also an important factor to consider. Smaller machines are suitable for producing smaller parts while larger machines are needed for larger parts and higher volume production. Make sure you choose the right machine size to meet your needs.
Quality control
Proper quality control measures are necessary to ensure the final product meets the desired standards. It is essential to regularly check the product for defects and make any necessary adjustments to the manufacturing process.
Maintenance
Regular maintenance of the injection molding machine and the mold is critical to ensure smooth and consistent production. Schedule regular maintenance to avoid deterioration of components.
Plastic injection molding is a manufacturing process used to produce a wide range of plastic products, from small toys to complex automotive components. The process involves melting plastic pellets and injecting the molten material under high pressure into a mold.
The first step in plastic injection molding is the design of the mold. This is typically done using computer-aided design (CAD) software to create a 3D model of the part or product. The mold is then produced using either CNC machining or electrical discharge machining.
Once the mold is ready, the plastic pellets are loaded into the injection molding machine. The pellets are heated to their melting point and then injected into the mold cavity. The high pressure used during the injection process ensures that the plastic fills the entire mold and creates a uniform part.
After the molten plastic has cooled and solidified, the mold is opened and the finished part is ejected. The part is then inspected for any defects such as sink marks, voids, or warping. If the part meets the required specifications, it is ready for use. If not, adjustments to the mold are made to improve the next production run.
What Is the Use of Plastic Injection Model
Plastic injection molds are used in the manufacturing process of plastic products. The plastic injection molding process involves melting plastic pellets and injecting the molten material under high pressure into a mold cavity. The plastic then cools and solidifies into the desired shape, which is then ejected from the mold.
Injection molds are designed to create precise and complex shapes with high accuracy and consistency, making them ideal for producing large quantities of high-quality plastic parts. These molds can be customized to meet specific customer requirements and can be used to produce a wide range of plastic products, including automotive parts, medical devices, toys, packaging materials, and more. Plastic injection molds are an essential tool in the manufacturing process of plastic products, enabling precise, efficient, and cost-effective production of high-quality plastic parts.
Factory
Deep Mold provides our clients a total and complete project management from concept to prototyping, through mold design, mold making, injection parts to assembly products of surface finish and finally the shipment at the destination. Our team has rich experience in molds and high quality parts, we have a whole set of advanced mold processing systems and high precision.
FAQ
Q: What is plastic injection molding process?
Q: What plastic is injection Moulded?
Q: What are plastic injection molds used for?
Q: What are the 4 stages of injection moulding?
Q: Is plastic injection molding difficult?
Q: Can all plastics be injection molded?
Q: Why would a plastic product be injection Moulded?
Q: Who needs plastic injection molding?
Q: What is the difference between injection and moulding?
Q: What is the difference between injection molding and molding?
Q: Why is injection molding so popular?
Q: Can PVC be injection molded?
Q: What is the strongest plastic for injection molding?
Q: How fast is injection moulding?
Q: How does plastic start for injection molding?
Q: Is plastic injection molding profitable?
Q: What is the difference between plastic machining and injection molding?
Q: What Are the Injection Molded Products?
Q: Can clear plastic be injection molded?
Q: What are injection molds made from?
